DATA SHEET ? SKY12324-73LF 1-BIT DIGITAL ATTENUATOR
Table 1. SKY12324-73LF Signal Descriptions
Pin #
1
J 2
Name
Description
RF port. Must be DC blocked.
Pin #
4
V1
Name
Description
DC control voltage. High input impedance
control port for the 8 dB bit. The high control
voltage applied to this pin must be within
0. 2 V o f the supply voltage applied to pin 3
or the part may be permanently damaged.
The low control voltage is 0 V nominal.
2
3
GND
J1
RF ground. Must be AC - coupled to ground.
RF port. Must be DC blocked.
5
6
N / C
V2
No connect
DC control voltage. High input impedance
control port for the 4 dB bit. The high control
voltage applied to this pin must be within
0. 2 V o f the supply voltage applied to pin 3
or the part may be permanently damaged.
The low control voltage is 0 V nominal.
Table 2. SKY12324-73LF Absolute Maximum Ratings
Parameter
RF input power (V CTL = 0/8 V)
Supply voltage
Control voltage
Operating temperature
Storage temperature
P IN
V S
V CTL
T OP
T STG
Symbol
Minimum
– 0.2
– 40
– 65
Maximum
+ 31
8
+8.0
+85
+150
Units
dBm
V
V
° C
° C
Note:
Exposure to maximum rating conditions for extended periods may reduce device reliability. There is no damage to device with only one parameter set at the limit and all other
parameters set at or below their nominal value. Exceeding any of the limits listed here may result in permanent damage to the device.
CAUTION : Although this device is designed to be as robust as possible, Electrostatic Discharge (ESD) can damage this device. This device
must be protected at all times from ESD. Static charges may easily produce potentials of several kilovolts on the human body
or equipment, which can discharge without detection. Industry-standard ESD precautions should be used at all times.
Electrical and Mechanical Specifications
The absolute maximum ratings of the SKY12324 - 73LF are
The state of the SKY12324 - 73LF is determined by the logic
provided in Table 4 .
provided in Table 2. Electrical specifications are provided in
Table 3 .
Typical performance characteristics of the SKY12324 - 73LF are
illustrated in Figures 3 through 8 .
Skyworks Solutions, Inc. ? Phone [781] 376 - 3000 ? Fax [781] 376 - 3100 ? sales@skyworksinc.com ? www.skyworksinc.com
2
February 22, 2011 ? Skyworks Proprietary Information ? Products and Product Information are Subject to Change Without Notice ? 200219E
